laser engraving machine

• Place of Origin:

   China

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1420096

• Place of Origin:

  China
• Specifications:
  Name: SF1318
  Processing area1300mm*1800mm (4.3feet*6feet)
  Laser power60W,80W,100W,130W,150W
  Laser type:Co2 glass laser tube
  Software:Laser cut 5.3
  Dimension:2.6mm*2m*1.3m
  Engraving speed1-6000mm/min
  Cutting speed1-1000mm/min
  Cutting thickness0-25mm acrylic (others determined by materials)
  Resolution ratio≤0.0125mm
  Position system:Red dot
  Interface:USB
  Minimum shaping characterletter 0.5mm, Chinese 0.5mm
  Support graphic formatDST, PLT, BMP, DXF
  Gross power1000W
  Driving mode:DC0.8A 24V stepper motor
  Cooling mode:Circulation water cooling
  Working voltage:AC220V/50HZ or 110V/60HZ or depend on customer
  Operating temperature0-45C
  Operating humidity:5-95%
  Packing:wooden box
  Guarantee time:1 year, laser tube 3 months
  Option:Rotary attachment for column materials
  Operation:Video to tell customer how to operate the machine
  Applicable materials:
  Non-metal materials such as acrylic, double color board, Plexiglas,
  Common glass, bamboo and wood, rubber, marble, granite and tiles, leather cloth etc.
  Applicable industries:
  Advertising industry, Billboards, artistic gifts, crystal ornaments, paper-cut, bamboo
  and wooden product, garment and leather, embroidery, decoration and upholster industry.
  Characteristics:
  ?Japanese technical engine running, making sure the products to run at high aped and high precision.
  ?The original binding beeline lead rail, the mechanic is running well and stable.
  ?Channel feeding, the feeding can be unlimited.
  ?The body of the machine adopts high quality aluminum, professional model and has the specification of strong and not easy for distortion.
  ?The main parts of the electrical line adopts the imported materials, the mainly controlled CMOS chip adopts double face CPU.
